MEMORY logicIDW3604000005
PNEU LOGIC ELEMENTS (MEMORY) (OSR)
Weight: 52.000 GRM
MEMORY logic
| EAN code: | 8024986016642 |
| Short description: | MEMORY logic |
| Quantity per package: | 10 |
| Minimum order quantity: | 10 |
| Unit of measure: | items |
| . | |
| Body material | Technopolymer |
| Flow-rate at 6 bar DP 1 bar (Nl/min) | 00100 |
| Functional denomination | Logic element MEMORIA |
| Lubricator (Type) | ISO UNI FD22 |
| Max input pressure (bar) | 008 |
| Max pilot pressure (bar) | 8 |
| Max temperature (°C) | 60 |
| Min input pressure (bar) | 00 |
| Min pilot pressure (bar) | 1,5 |
| Min temperature (°C) | -10 |
| Product's series | Pneumatic logic elements |
| Push-in fitting for pipe (Ø) | 4 |
| Thread type | Cylindrical |
